Sides Labeling Machine

Semi Automatic Flat Double Side Labeling Machine

Category： Sides Labeling Machine
Views：1591
Model:KPW-BC150
Labeling speed:30–60 pieces/min (double-side configuration)
Applicable Product Size:L(20mm～200mm);W(20mm～150mm);H(0.2～120mm)
Label size:Length 5–100 mm; width 20–150 mm
Product description：KPW-BC150 semi-automatic double-side flat labeling configuration, 30–60 pieces/min. Send flat-bottle dimensions and front/back label samples for configuration and a quotation.
INQUIRY

KPW-BC150 Double-Side Flat Labeling Machine

This semi-automatic configuration applies labels to the front and back faces of flat-sided products. It is intended for flat shampoo, cosmetic and similar containers with suitable label faces. Submit the actual product and both labels to confirm positioning and handling.

KPW-BC150 double-side flat-bottle label application illustration

Application illustration showing two label faces; this image is not an equipment photograph.

KPW-BC150 · double-side flat-bottle configurationModelKPW-BC150Labeling modeSemi-automatic, front and back labels on flat-sided productsLabeling speed30–60 pieces/min; subject to product, label size and handling conditionsLabeling accuracy±0.5 mm, excluding product and label variationApplicable product sizeLength 20–200 mm; width 20–150 mm; height 0.2–120 mmLabel sizeLength 5–100 mm; width 20–150 mmLabel roll76 mm core; maximum outer diameter 280 mmMachine sizeApproximately 1200 × 1000 × 810 mmPower supply110 / 220 V, 50 / 60 Hz, single phaseThe 30–60 pieces/min range applies to this double-side configuration. Confirm the actual product and both label samples with the quotation.

Before requesting a quotation

Provide product dimensions, the shape and flatness of both label faces, label length and width, roll direction, required output and available power supply. Confirm whether the product is loaded manually or connected to another process.

Send your bottle and label requirements
